Air Flow Laboratory
Air Flow Laboratory
- Room size 8 x 12 m, height 2,5 ... 4,7 m
- Measurements: Air velocity, air temperature, turbulence, pressure loss, leakage, smoke tests, full scale tests.
Standards
EN ISO 5167-2: Measurement of fluid flow by means of pressure differential devices inserted in circular cross-section conduits running full. Part 2: Orifice plates.
EN 12238: Ventilation for buildings. Air terminal devices. Aerodynamic testing and rating for mixed flow application.
EN 1751: Ventilation for buildings. Air terminal devices. Aerodynamic testing of damper and valves.
EN 14277: Ventilation for buildings. Air terminal devices. Method for airflow measurement by calibrated sensors in or close to ATD/plenum boxes
Air Flow Measurements
- Test rig for air flow and pressure measurements.
- Capacity 15 – 8000 l/s.
Standards
EN ISO 5167-2: Measurement of fluid flow by means of pressure differential devices inserted in circular cross-section conduits running full. Part 2: Orifice plates.
EN 1751: Ventilation for buildings. Air terminal devices. Aerodynamic testing of damper and valves.
EN 14277: Ventilation for buildings. Air terminal devices. Method for airflow measurement by calibrated sensors in or close to ATD/plenum boxes.
