Clean Rooms Solutions by FläktGroup
FläktGroup clean room HVAC solutions offer impeccable quality and meet the strictest hygiene requirements for the pharmaceutical and healthcare industries.
Clean Room Technology by FläktGroup
Numerous international manufacturers work with FläktGroup‘s Clean Room Technology as a result of our expertise in developing reliable and effective contamination control methods for Clean Rooms.
Clean Room services from FläktGroup permit users to coordinate all critical parameters precisely with the requirements of respective production processes and to systematically control decontamination of room air. These solutions control air pressure, temperature, and moisture – especially the contamination with fine dust, skin particles and bacteria – and keep these contaminants away from products and processes.
Effective and precise clean room HVAC design is essential for semiconductor production and pharmaceutical industries, as well as companies in the chemical industry, space technology, and optics and laser technology perform research and production; where we see that conditions in these industries are increasingly relying upon Clean Room conditions.
Technical, chemical, and biological quality products with highly sensitive manufacturing processes are further processed in hermetically sealed areas that demand room air that is virtually dust-free. The manufacturing process itself, however, requires ambient air absolutely free of particulates.
For any process, whether human, mechanical or chemical, the condition of the surrounding air is vital.
Not only does the air have to be clean, but it also has to be the correct temperature, correct humidity, be odourless, and contain the correct amount of fresh air. It has to be introduced into the space so that there is very little noise and very little draught.
For clean rooms surfaces need to be accurately controlled to maintain velocities, patterns or pressure cascades. FläktGroup not only has the most comprehensive product portfolio in the market – we develop and manufacture our own systems to take all of the above factors into consideration.
Your Benefits
- We are your system provider and one stop supplier
- We have a deep in-house value chain available
- We provide global reach combined with local knowledge
- We use high quality components, such as heat recovery elements, designed and manufactured by FläktGroup
- We deliver products from our own high-end manufacturing inside of Europe
- We have many years of experience
- We are your single source for the complete clean room build (shell and space itself)
- We bring air from the outside into the clean room exactly at your requirements with all the necessary air treatment processes
- We adapt the products to your requirements
- We use the most efficient HVAC solutions
Clean Room Solutions
You might also be interested in:
-
Producing pharmaceuticals requires a sterile environment and a very high level of cleanliness. Ventilation must provide the correct contamination & temperature control.
-
The creation of medical devices requires a totally clean and germ-free indoor space.
-
When it comes to handling critical substances, an uncontaminated environment is of high importance.
-
FläktGroup Clean Rooms meet challenging demands up to ISO Class 5 or even better to protect products from contamination.
-
During an operation human life must be safeguarded to avoid contamination from the surrounding area.
CONTACT OUR SALES TEAM
USE OUR SELECTION TOOLS
VIEW OUR REFERENCES
CARE Service & Controls
Our Teams can be on hand to support with design, installation, validation, controls and BMS.
Find out more by contacting our local teams!
Products
-
EHSD CIRCULAR FLOW VARIATOR
- Easy and Quick Selection
- Insulated casing
- Integrated orifice plate for air measurement
- FG compact controller as standard
-
CAIRplus AIR HANDLING UNIT
- CAIRplus is the tailor-made premium range of modular air handling units for every customer requirement
- Environmentally-friendly design means an energy recovery system with high efficiency is available for every configuration
- Clean surfaces and ease of cleaning guarantee hygienic standards to VDI6022
- All units can be supplied with FläktGroup integrated controls ISYteq 4.0
- T2/TB2/L1/D1 Eurovent certified casing
-
eQ MASTER® AIR HANDLING UNIT
- Tailor made for customer needs
- Energy Efficient and optimized with integrated control
- Large variety of high efficiency components
-
Fresh Heaven MAXX LAMINAR AIRFLOW UNIT
- Size upon Customer’s demands
- Air delivered by AHU (FHM) or recirculation mode with power module (FHM P)
- H13, H14 or U15 filters with U-shaped or fluid gasket
- Casing in stainless-steel / steel in RAL 9010, height 450 mm (FHM) / 550 mm (FHM P)
- Various outlets (perforated stainless-steel / steel in RAL 9010, polyester fabric)
- Equipped with autonomous automatics (local control via Siemens LOGO! panel)
-
CGx Ceiling Air Outlet HEPA FILTER DIFFUSORS
- Used in pharmaceutical industry, laboratories, hospitals, microbiology, electronic industry, and food industry
- Easy integration in all types of FläktGroup suspended ceilings
- Filter classes H13 to U15 in an aluminum frame, with dry or fluid seal
- For turbulent displacement flow
- Integrated pressure-gauge connection for monitoring pressure drop
- Tube for applying test aerosol (measuring of concentration)
-
GLFC 2150-2600 DA2 (286 - 1212 kW)
- Version with 2 screw compressors
- SEPR-HT values up to 6.3
- ErP 2021 compliant with EU 2016/2281
- Available as Standard or Super-Low noise (SL) versions
-
SANDWICH PANELS
- The panels have a sandwich structure (two steel sheets with thermal insulation between them), with painted or stainless-steel sheet facing
- Custom colors and various core options are possible with minimal particle release
- R-panels 62 mm thick, M-panels and Me-panels are 60 mm thick
- Matching flush glassed-in panels (non-opening windows) and doors are available
- All joints are sealed by permanently elastic silicone in a color closely matching the panel color
- Round connections to the floor, suspended ceiling, and inner corners (Radius profiles system) are available
- The panels offer easy maintenance, effective sanitation, and resistance to disinfectants
- They ensure tightness to maintain over pressure or under pressure in the clean room
-
Inwall FACINGS
- The ideal solution for adapting existing rooms into clean rooms.
- Easy and quick fixation to structural walls
- All panels are prefabricated – minimal adjustments on site
- All joints sealed with silicone
- Panels connected via conductive cables are grounded to the earthing point
-
DOORS & WINDOWS
- An automatic drop-down seal integrated into the door leaf enhances the air-tightness of a door
- Being flush with sandwich wall partitions ensures easy maintenance and flawless disinfection
- An interlock system equipped with signaling units prevents both doors in an airlock room from being opened simultaneously, effectively reducing the risk of contamination
- Doors can be opened manually or automatically with automatic drive
- Transfer doors are used as partitions of transfer boxes (passive or with filtered airflow)
- Accessories available include automatic drives, door closers, mirrors, windows with sunblinds, windows made from float glass or safety glass (ESG, VSG), automatic drop-down seals, stainless-steel kick plates, electromechanical and electromagnetic locks, signaling panels (semaphore), and many more.
-
EXHAUST-AIR COMPONENTS
- Reliable ventilation of anesthetic gases, particles and exhaust of room air burdened with microbes
- Various choices of extract-air components
- Seamless integration of extract-air components in all types of wall panels and facings
-
CEILINGS
- LS ceiling – clip-in light ceiling
- KS ceiling – grid cassette ceiling
- KSH ceiling – walkable Alucore grid ceiling
- RS ceiling – walkable sandwich panel ceiling.
- A minimum number of particles is released from the panel surface
- Ease of installation, cleaning and sanitation, resistance to conventional disinfectants
- Joints between cassettes are sealed using permanently elastic sealant
